‘ND’ Series – Mini Valves (Series M22)
Series ‘ND’ direct acting valves consist of the more compact M22 coils and armature.
They have a fixed orifice of 1.1mm and are available in both 1/8″ and 1/4″ BSP port sizes
They are available in various types of coils ranging from 12VAC till 230VAC and 12VDC till 24VDC
| Model No | Discription | Size(BSP) | Seal Kit No |
|---|---|---|---|
| ND111* | 2/2 (2 Way) Normally Closed Direct Acting Solenoid Valve | 1/8″ | SKND111 |
| ND311* | 3/2 (3 Way) Normally Closed Direct Acting Solenoid Valve | 1/8″ | SKND311 |
*Add Voltage & Connector Suffix While Ordering
| Model No | Discription | Size(BSP) | Seal Kit No |
|---|---|---|---|
| ND211* | 2/2 (2 Way) Normally Closed Direct Acting Solenoid Valve | 1/8″ | SKND211 |
| ND411* | 3/2 (3 Way) Normally Closed Direct Acting Solenoid Valve | 1/8″ | SKND411 |
*Add Voltage & Connector Suffix While Ordering
| Model No | Discription | Size(BSP) | Seal Kit No |
|---|---|---|---|
| NDG-02* | Gang Manifold Assembly For 2 Valves | 1/8″ | SKNDG-02 |
| NDG-03* | Gang Manifold Assembly For 3 Valves | 1/8″ | SKNDG-03 |
| NDG-04* | Gang Manifold Assembly For 4 Valves | 1/8″ | SKNDG-04 |
| NDG-05* | Gang Manifold Assembly For 5 Valves | 1/8″ | SKNDG-05 |
| NDG-06* | Gang Manifold Assembly For 6 Valves | 1/8″ | SKNDG-06 |
| NDG-07* | Gang Manifold Assembly For 7 Valves | 1/8″ | SKNDG-07 |
| NDG-08* | Gang Manifold Assembly For 8 Valves | 1/8″ | SKNDG-08 |
*Add Voltage & Connector Suffix While Ordering
